8-24 Phaser 4500 Service Manual
Nudger Gear
(PL5.1.10)
1. Nudger Gear 5. Boss (Lift Up)
2. Nudger Roller 6. Left Holder
3. Nudger Support 7. Hooks
4. No Paper Actuator
s4500-163
4
6
7
7
7
5
6
3
4
5
6
1
2
