10-12 Phaser 4500 Service Manual
Duplex Unit Plug/Jack Locator
P/J Locator Table
P/J Coordinates Remarks
50 G-304 Connects the Duplex Unit Harness and Duplex Unit PWBA
51 G-304 Connects the Duplex Unit Motor and Duplex Unit PWBA
52 G-304 Connects the Duplex Unit Harness COVER and Duplex Unit PWBA
53 E-303 Connects the Duplex Unit Harness SNR and Duplex Unit PWBA
54 E-303 Connects the Duplex Unit Fan and Duplex Unit PWBA
56 G-305 Connects the Duplex Unit Harness Ground and Duplex Unit PWBA
520 H-305 Connects the Duplex Unit Switch and Duplex Unit Harness
530 C-303 Connects the Duplex Unit Sensor and Duplex Unit Sensor Harness
560 H-307 Connects the Duplex Unit Harness Ground and Ground Plate
Assembly
2750 I-304 Connects the Duplex Unit Harness and LVPS Harness Assembly
