Error Messages and Codes 3-51
Stacker Error
Error Code
E9-2: Stacker Unit failure
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Stacker Assembly Harness 1
■ HVPS/Engine Logic Board
■ Stacker PWBA
■ Stacker Assembly Harness 2
■ “Stacker General Wiring Diagram” on page 10-31
■ “Stacker Signal Diagram” on page 10-32
■ “Stacker Plug/Jack Locator” on page 10-14
Troubleshooting Procedure
Steps Actions and Questions Yes No
1
Remove the Stacker, re-install it, and turn
the power ON.
Does the error still occur?
Go to “Stacker
PWBA” on
page 4-59.
Problem solved.
To Next Page
