Xerox Phaser 4500 Service Manual

General Troubleshooting 4-33
Feed Clutches
Troubleshooting Reference
Applicable Parts Wiring and Plug/Jack Map References
■ Feed Clutch
■ Tray 1 Har ness
■ Tray 2 Har ness
■ Chute Harness
■ HVPS/Engine Logic Board
■ LVPS
■ “150-Sheet Feeder, 550-Sheet Feeder, Main Fan”
on page 10-22
■ “Print Engine General Wiring Diagram” on
page 10-17
■ “Print Engine Plug/Jack Locator” on page 10-3
Troubleshooting Procedure
Steps Actions and Questions Yes No
1
Check the Chute Harness:
1. Disconnect P/J24 from the HVPS/
Engine Logic Board.
2. Test for continuity across the following
points:
■ J24-13 <=> J245-6
■ J24-12 <=> J245-7
■ J24-5 <=> J248-1
■ J24-4 <=> J248-2
Are all continuous?
Go to step 2. Replace the
Chute Harness.
2
Check the Tray 1 and Tray 2 Harnesses:
1. Remove the Feed Clutch.
2. Disconnect P/J245 (Tray 1 Harness) or
P/J248 (Tray 2 Harness).
3. Test for continuity across the following
points:
Tray 1 Harness:
■ P/J245-8 <=> P/J242-1
■ P/J245-7 <=> P/J242-2
Tray 2 Harness:
■ P/J248-5 <=> P/J247-1
■ P/J248-4 <=> P/J247-2
Are all continuous
Go to step 3. Replace Tray 1 or
Tray 2 Harness.
3
Check the resistance of the Feed Clutches:
Measure the resistance between:
■ P/J242-1 <=> P/J242-2 (Tray 1 Feed
Clutch)
■ P/J247-1 <=> P/J247-2 (Tray 2 Feed
Clutch)
Does the resistance measure 172 ohms
+/-10% (at 20° C)?
Go to step 4. Replace Feed
Clutch Assembly.
(page 8-26,
page 8-36,
page 8-110)
