Xerox Phaser 4500 Service Manual

Print-Quality Troubleshooting 5-41
4
Warning: Allow the Fuser Assembly
to cool before removing.
1. Open the Rear Cover and remove
the Fuser Assembly.
2. Manually rotate the Fuser Drive
Gear and inspect the Heat Roller.
3. Open the Fuser Jam Access
Cover.
4. Manually rotate the Fuser Drive
Gear and inspect the Pressure
Roller.
Are the Heat Roller and the
Pressure Roller free of surface
defects and contamination.
Go to step 5. Clean or replace the
Fuser Assembly
(page 8-54).
5
Replace the following, in order, until
the defective component is found:
■ Transfer Roller Assembly
(page 8-55)
■ Fuser Assembly (page 8-54)
■ HVPS Engine Logic PWB
(page 8-89)
■ Print Cartridge Right Side Guide
(page 8-58)
Residual Image Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
