KTM 300 EXC TPI 2019 Repair Manual

18 ENGINE
196
R02882-10
–
Remove screws
cq
and
cr
.
– Take off the engine braces.
R02881-10
–
Remove nut
cs
.
– Remove the swingarm pivot.
– Carefully pull the swingarm back, and secure the swingarm.
R02883-10
–
Remove screws
ct
.
R02888-10
– Lift out the engine sideways to the right.
Info
Pay attention to the oil pump.
The help of an assistant is useful in this step.
Make sure that the engine is sufficiently secured
against falling over.
Protect the frame and attachments against damage.
18.3 Installing the engine
R02888-10
Main work
– Position the engine in the frame.
Info
The help of an assistant is useful in this step.
Make sure that the engine is sufficiently secured
against falling over.
Protect the frame and attachments against damage.
Pay attention to the oil pump.

KTM 300 EXC TPI 2019 Specifications

General

Displacement	293.2 cm³
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP XPLOR PDS shock absorber
Seat Height	960 mm
Ground Clearance	370 mm
Fuel Tank Capacity	9.5 liters
Engine Type	2-stroke
Fuel System	Transfer Port Injection (TPI)
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP Xplor 48
Front Brake	Disc brake
Rear Brake	Disc brake 220 mm
