KTM 300 EXC TPI 2019 Repair Manual

18 ENGINE
208
D04423-10
–
Remove nuts
5
.
Info
Raise the cylinder slightly to be able to remove the
front nuts.
– Carefully slide the cylinder up and take it off.
D04425-10
–
Take off gasket
6
.
18.4.11 Removing the piston
D04430-10
(All 250 models)
– Uncover the crankcase.
–
Remove piston ring lock
1
.
– Remove the piston pin.
– Take off the piston.
D04431-10
(All 300 models)
– Uncover the crankcase.
–
Remove piston ring lock
1
.
– Remove the piston pin.
– Take off the piston.

KTM 300 EXC TPI 2019 Specifications

General

Displacement	293.2 cm³
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP XPLOR PDS shock absorber
Seat Height	960 mm
Ground Clearance	370 mm
Fuel Tank Capacity	9.5 liters
Engine Type	2-stroke
Fuel System	Transfer Port Injection (TPI)
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP Xplor 48
Front Brake	Disc brake
Rear Brake	Disc brake 220 mm
