KTM 300 EXC TPI 2019 Repair Manual

18 ENGINE
210
R04641-10
–
Remove screws
3
.
R04642-10
– Take off the clutch cover at the top and slip out the linkage.
Info
Ensure that the kick starter shaft remains in the engine
case.
D04444-10
–
Remove dowels
4
and clutch cover gasket
5
.
D04445-10
–
Remove screws
6
.
– Take off the bearing support with the linkage and angle lever.
18.4.14 Removing the clutch discs
D04446-10
–
Remove screws
1
.
–
Take off spring retainer
2
.

KTM 300 EXC TPI 2019 Specifications

General

Displacement	293.2 cm³
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP XPLOR PDS shock absorber
Seat Height	960 mm
Ground Clearance	370 mm
Fuel Tank Capacity	9.5 liters
Engine Type	2-stroke
Fuel System	Transfer Port Injection (TPI)
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP Xplor 48
Front Brake	Disc brake
Rear Brake	Disc brake 220 mm
