KTM 300 EXC TPI 2019 Repair Manual

TECHNICAL DATA 26
315
Screw, intermediate clutch cover M6 10 Nm (7.4 lbf ft)
Screw, kick starter stop plate M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, outer clutch cover M6 8 Nm (5.9 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, starter motor bearing bush M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, starter motor protection cap M6 8 Nm (5.9 lbf ft)
Screw, vacuum connections M6 8 Nm (5.9 lbf ft)
Loctite
®
2701™
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Screw, balancer shaft M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, cylinder head M8 27 Nm (19.9 lbf ft)
Screw, kick starter M8 25 Nm (18.4 lbf ft)
Loctite
®
2701™
Nut, cylinder base M10 35 Nm (25.8 lbf ft)
Screw, drive chain engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Stud, cylinder base M10 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, cylinder head temperature
sensor
M10x1.25 12 Nm (8.9 lbf ft)
Nut, rotor M12x1 60 Nm (44.3 lbf ft)
Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Spark plug M14x1.25 25 Nm (18.4 lbf ft)
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
648™
Nut, primary gear M18LHx1.5 150 Nm (110.6 lbf ft)
Loctite
®
648™
26.4 Capacities
26.4.1 Gear oil
Gear oil 0.80 l (0.85 qt.) Engine oil (15W/50) ( p. 358)
26.4.2 Engine oil
2-stroke oil tank content approx. 0.7 l (0.7 qt.) Engine oil, 2-stroke ( p. 358)
26.4.3 Coolant
Coolant 1.2 l (1.3 qt.) Coolant ( p. 358)

KTM 300 EXC TPI 2019 Specifications

General

Displacement	293.2 cm³
Bore x Stroke	72 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP XPLOR PDS shock absorber
Seat Height	960 mm
Ground Clearance	370 mm
Fuel Tank Capacity	9.5 liters
Engine Type	2-stroke
Fuel System	Transfer Port Injection (TPI)
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP Xplor 48
Front Brake	Disc brake
Rear Brake	Disc brake 220 mm
