3-48 ENGINE
• Apply THREAD LOCK SUPER to the bolts, and then tighten
them to the specified torque.
# Starter clutch bolt: 25 N·m (2.5 kgf-m, 18.0 lb-ft)
* 99000-32030: THREAD LOCK SUPER “1303”
or equivalent
OIL PUMP
REMOVAL
• Remove the oil pump assembly 1 with oil return pump.
DISASSEMBLY
• Remove the oil return pump outer rotor 1, inner rotor 2 and
pin 3.
INSPECTION
• Rotate the oil pump by hand and check that it moves
smoothly.
• If it does not move smoothly, replace the oil pump assembly.
"
• Inspect the outer rotor 1 and inner rotor 2 for any scratches
or other damage. If any damages are found, replace them
with new ones.
* Do not attempt to disassemble the oil pump assem-
bly.
* The oil pump is available only as an assembly.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
