SERVICING INFORMATION 11-45
FUEL TANK INSTALLATION
1 Heat shield 6 Fuel tank cushion
2 Fuel pump 7 Rear fender cover cushion
3 Clamp 8 Apply instant adhesive to the shaded portion.
4 Face the tip of clamp to the backward. 9 Fuel tank rear bracket
5
Face the arrow mark to the forward, when install-
ing the fuel tank cap.
0
Attach the front of fuel tank cushion to the rein-
forcement of frame.
Outside
Forward

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
