12-10 EMISSION CONTROL INFORMATION
HEATED OXGEN SENSOR (HO2S) INSPECTION (FOR E-02, 19, 24)
• Disconnect the HO2 sensor lead wire coupler. (!5-79)
• Inspect the HO2 sensor and its circuit referring to flow table of
the malfunction code C44 or 64 (P0156/P0161 or
P0130/P0135).
• Check the resistance between the terminals of the HO2 sen-
sor.
" Resistance: 4.0 – 5.5 Ω at 23 °C (73.4 °F)
(White – White)
# 09900-25008: Multi-circuit tester set
$ Tester knob indication: Resistance (Ω)
If the resistance is not within the standard range, replace the
HO2 sensor with a new one.
NOTE:
* Temperature of the sensor affects resistance value largely.
* Make sure that the sensor heater is at correct temperature.
&
%
• Installation is in the reverse order of removal.
%
• Tighten the sensor unit to the specified torque.
' HO2 sensor: 48 N·m (4.8 kgf-m, 34.5 lb-ft)
#1
#2
Do not remove the HO2 sensor while it is hot.
Be careful not to expose it to excessive shock.
Do not use an impact wrench while removing or
installing the HO2 sensor unit.
Be careful not to twist or damage the sensor lead wire.
Do not apply oil or other materials to the sensor air
hole.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
