Suzuki VZR1800 2008 User Manual

CHASSIS 9-73
TIRE AND WHEEL
TIRE REMOVAL
The most critical factor of tubeless tire is the seal between the
wheel rim and the tire bead. For this reason, it is recommended
to use a tire changer that can satisfy this sealing requirement
and can make the operation efficient as well as functional.
For operating procedures, refer to the instructions supplied by
the tire changer manufacturer.
NOTE:
When removing the tire in the case of repair or inspection, mark
the tire with a chalk to indicate the tire position relative to the
valve position.
Even though the tire is refitted to the original position after
repairing puncture, the tire may have to be balanced again since
such a repair can cause imbalance.
INSPECTION
WHEEL
Wipe the wheel clean and check for the following:
• Distortion and crack
• Any flaws and scratches at the bead seating area.
• Wheel rim runout (!9-10)
TIRE
Tire must be checked for the following points:
• Nick and rupture on side wall
• Tire tread depth (!2-27)
• Tread separation
• Abnormal, uneven wear on tread
• Surface damage on bead
• Localized tread wear due to skidding (Flat spot)
• Abnormal condition of inner liner

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
