Suzuki VZR1800 2008 User Manual

– 9 –
WATTAGE
Unit: W
ITEM SPECIFICATION NOTE
Generator no-load voltage
(When engine is cold)
70 V (AC) and more at 5 000 r/min
Regulated voltage 14.0 – 15.5 V at 5 000 r/min
Starter relay resistance 3 – 6 Ω
Battery Type
designation
FTZ16-BS
Capacity 12 V 64.8 kC (18 Ah)/10 HR
Fuse size
Headlight
HI 10 A
LO 10 A
Fuel 10 A
Ignition 15 A
Turn signal 15 A
Fan motor 15 A
Main 30 A
Starter motor brush length Standard 12.5 (0.49)
Limit 6.0 (0.24)
ITEM
SPECIFICATION
E-03, 28, 33 E-02, 19, 24
Headlight
HI 60 ←
LO 55 ←
Position light 5
Brake light/Taillight LED ←
Front turn signal light/Position light 21/5
Front turn signal light 21
Rear turn signal light 21 ←
Speedometer LED ←
Tachometer LED ←
Turn signal indicator light LED ←
High beam indicator light LED ←
Neutral indicator light LED ←
Fuel level indicator light LED ←
Coolant temperature/Oil pressure
indicator light
LED ←
FI indicator light LED ←
License light 5 ←
VZR1800 (’07-MODEL)13- 9

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
