9-76 CHASSIS
• In this condition, check the “rim line” B cast on the tire side
walls. The line must be equidistant from the wheel rim all
around. If the distance between the rim line and wheel rim
varies, this indicates that the bead is not properly seated. If
this is the case, deflate the tire completely and unseat the
bead for both sides. Coat the bead with lubricant and fit the
tire again.
• When the bead has been fitted properly, adjust the pressure
to specification.
• As necessary, adjust the tire balance.
$
& Cold inflation tire pressure
BALANCER WEIGHT INSTALLATION
• When installing the balancer weights to the wheel, set the two
balancer weights A on both sides of wheel rim.
$
Do not run with a repaired tire at a high speed.
Front Rear
Solo riding
250 kPa
(2.50 kgf/cm², 36 psi)
290 kPa
(2.90 kgf/cm², 42 psi)
Dual riding
250 kPa
(2.50 kgf/cm², 36 psi)
290 kPa
(2.90 kgf/cm², 42 psi)
Weight difference between the two balancer weights
must be less than 10 g (0.02 lb).

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
