Suzuki VZR1800 2008 User Manual

COOLING AND LUBRICATION SYSTEM 8-19
ENGINE LUBRICATION SYSTEM CHART
SECONDARY
BEVEL GEARS
AND BEARING
PRIMARY DRIVEN
GEAR BEARING
SECONDARY
DRIVEN
BEVEL SHAFT
SECONDARY
DRIVEN
GEAR BEARING
#1 PISTON PIN
BEARING
IDER SHAFT AND
BEARING
CAM CHAIN
TENSION
ADJUSTER
#1 CAMSHAFT
JOURNALS,
CAM FACES
AND TAPPETS
#1 EXHAUST
CAMSHAFT
#2 EXHAUST CAMSHAFT
#2 CYLINDER HEAD
#2 CYLINDER
#2 OIL JET
ORIFICE GENERATOR
#2 CAM CHAIN
#2 EXHAUST CAMSHAFT
JOURNAL HOLDER
#2 CAMSHAFT JOURNALS,
CAM FACES AND TAPPETS
#2 CAM CHAIN
TENSION ADJUSTER
#2 INTAKE CAMSHAFT
JOURNAL HOLDER
#1 CAMSHAFT JOURNALS,
CAM FACES AND TAPPETS
#1 INTAKE
CAMSHAFT
#1 EXHAUST
CAMSHAFT
JOURNAL HOLDER
#1 PISTON AND
CYLINDER WALL
OIL PIPE
OIL JET
OIL JET
COUNTERSHAFT
GEARS AND
BUSHINGS
BALANCER
SHAFT LEFT-SIDE
BEARING
DRIVESHAFT
RIGHT-SIDE BEARING
DRIVESHAFT
GEARS AND
BUSHINGS
CLUTCH
PUSH PIECE
COUNTERSHAFT
LEFT-SIDE
BEARING
CLUTCH PLATES
BALANCER SHAFT
#1 PISTON
COOLING OIL JET
OIL PASSAGE in
OIL PAN
#1 CAM CHAIN
#1 CYLINDER HEAD
#1 CYLINDER #1 OIL JET
#1 INTAKE
CAMSHAFT
JOURNAL HOLDER
#2 INTAKE
CAMSHAFT
#2 CAMSHAFT
JOURNALS,
CAM FACES AND
TAPPETS
#2 SUB-GALLERY
By-pass
OIL FILTER
LOWER CASE
OIL PUMP
OIL STRAINER
OIL PASSAGE in OIL PAN
OIL PRESSURE SWITCH
OIL RETURN PUMP
OIL STARINER
OIL PRESSURE
REGULATOR
#2 PISTON AND
CYLINDER WALL
#2 PISTON
COOLING OIL JET
CRANKSHAFT
LEFT-SIDE
JOURNAL BEARING
CRANKSHAFT
RIGHT-SIDE
JOURNAL BEARING
#2 PISTON PIN BEARING
IDRER SHAFT AND
BEARING

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
