COOLING AND LUBRICATION SYSTEM 8-5
RADIATOR DISASSEMBLY
• Remove the reservoir tank 1.
• Remove the coolong fan 2 and shield 3.
• Remove the radiator guard 4 .
RADIATOR CAP INSPECTION
• Fit the cap 1 to the radiator cap tester 2.
• Build up pressure slowly by operating the tester. Make sure
that the pressure build-up stops at 93 – 123 kPa (0.93 – 1.23
kgf/cm
2
, 13.2 – 17.5 psi) and that, with the tester held stand-
still, the cap is capable of holding that pressure for at least 10
seconds.
• Replace the cap if it is found not to satisfy either of these two
requirements.
$ Radiator cap valve opening pressure
Standard: 93 – 123 kPa
(0.93 – 1.23 kgf/cm
2
, 13.2 – 17.5 psi)

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
