CHASSIS 9-35
• Remove the O-ring 2.
INSPECTION AND DISASSEMBLY
WHEEL DAMPER
• Inspect the damper for wear or damage.
• Replace the damper if there is anything unusual.
• Remove the dampers with a screw driver.
WHEEL (! 9-73)
WHEEL AXLE (!9-9)
TIRE (!2-27 and 9-73)
BRAKE DISC (!9-69)
• Remove the brake disc 1.
WHEEL BEARINGS
• Inspect the play of the wheel bearings by finger while they are
in the wheel. Rotate the inner race by finger to inspect for
abnormal noise and smooth rotation.
• Replace the bearing in the following procedure if there is any-
thing unusual.
• Remove the dust seal with the special tool.
% 09913-50121: Oil seal remover
$
The removed dust seal must be replaced with a new
one.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
