CHASSIS 9-59
MASTER CYLINDER REMOVAL AND
DISASSEMBLY
• Drain the brake fluid. (!9-53)
• Disconnect the front brake light switch lead wire coupler 1.
• Place a rag underneath the union bolt 2 on the master cylin-
der to catch any split brake fluid. Remove the union bolt and
disconnect the brake hose.
$
• Remove the right rear view mirror 3 and master cylinder
assembly 4.
• Remove the front brake light switch 5.
• Remove the nut and bolt 6 and brake lever 7.
• Remove the dust boot 8 and the snap ring 9.
Immediately and completely wipe off any brake fluid
contacting any part of the motorcycle. The fluid reacts
chemically with paint, plastics and rubber materials,
etc. and will damage them severely.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
