COOLING AND LUBRICATION SYSTEM 8-15
• Remove the oil seal 9.
NOTE:
If there is no abnormal condition, the oil seal removal is not nec-
essary.
!
INSPECTION
MECHANICAL SEAL
• Visually inspect the mechanical seal for damage, with particu-
lar attention given to the sealing face.
• Replace the mechanical seal that shows indications of leak-
age. Also replace the seal ring if necessary.
OIL SEAL
• Visually inspect the oil seal for damage, with particular atten-
tion given to the lip.
• Replace the oil seal that shows indications of leakage.
IMPELLER SHAFT JOURNAL
• Visually inspect the journal for damage or scratch.
• Replace the water pump body if necessary.
SEAL WASHER
• Visually inspect the seal washer for damage, with particular
attention given to the sealing face.
• Replace the seal washer that shows indications of leakage.
The removed oil seal must be replaced with a new one.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
