9-30 CHASSIS
REMOVAL
• Remove the right rear view mirror 1.
• Remove the brake master cylinder 2.
• Remove the throttle grip end cap 3.
• Disconnect the front brake switch lead wire coupler 4 and
remove the right handlebar switch 5.
• Disconnect the throttle cable by removing the throttle grip 6.
• Remove the left handlebar switch 7 and disconnect the
clutch lever switch lead wire coupler 8.
• Remove the left handlebar grip end cap 9 and left handlebar
grip 0.
• Remove the left rear view mirror A and loosen the clutch
lever holder bolt B.
• Remove the handlebar clamp bolt caps C.
• Remove the handlebar clamp bolts D.
• Remove the handlebar with the clutch lever holder.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
