CHASSIS 9-75
TIRE INSTALLATION
• Apply tire lubricant to the tire bead.
• When installing the tire onto the wheel, observe the following
points.
$
• When installing the tire, the arrow A on the side wall should
point to the direction of wheel rotation.
• Align the chalk mark put on the tire at the time of removal with
the valve position.
• For installation procedure of tire onto the wheel, follow the
instructions given by the tire changer manufacturer.
• Bounce the tire several times while rotating. This makes the
tire bead expand outward to contact the wheel, thereby facili-
tating air inflation.
• Inflate the tire.
)
* Do not reuse the valve which has been once
removed.
* Never use oil, grease or gasoline on the tire bead in
place of tire lubricant.
* Do not inflate the tire to more than 400 kPa (4.0
kgf/cm², 57 psi). If inflated beyond this limit, the tire
can burst and possibly cause injury. Do not stand
directly over the tire while inflating.
* In the case of preset pressure air inflator, pay special
care for the set pressure adjustment.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
