COOLING AND LUBRICATION SYSTEM 8-1
8
COOLING AND LUBRICATION SYSTEM
CONTENTS
ENGINE COOLANT..................................................................................... 8- 2
COOLING CIRCUIT ..................................................................................... 8- 3
COOLING CIRCUIT INSPECTION........................................................ 8- 3
RADIATOR AND WATER HOSE................................................................. 8- 4
RADIATOR REMOVAL AND DISASSEMBLY ..................................... 8- 4
RADIATOR DISASSEMBLY ................................................................. 8- 5
RADIATOR CAP INSPECTION............................................................. 8- 5
RADIATOR INSPECTION AND CLEANING......................................... 8- 6
RADIATOR REASSEMBLY .................................................................. 8- 6
RADIATOR INSTALLATION................................................................. 8- 6
WATER HOSE INSPECTION................................................................ 8- 7
COOLING FAN............................................................................................. 8- 8
INSPECTION ......................................................................................... 8- 8
COOLING FAN RELAY INSPECTION.................................................. 8- 8
ECT SENSOR .............................................................................................. 8- 9
REMOVAL ............................................................................................. 8- 9
INSPECTION ......................................................................................... 8- 9
INSTALLATION..................................................................................... 8-10
THERMOSTAT............................................................................................. 8-11
REMOVAL ............................................................................................. 8-11
INSPECTION ......................................................................................... 8-11
INSTALLATION..................................................................................... 8-12
WATER PUMP ............................................................................................. 8-13
REMOVAL AND DISASSEMBLY ......................................................... 8-13
INSPECTION ......................................................................................... 8-15
REASSEMBLY AND INSTALLATION.................................................. 8-16
ENGINE LUBRICATION SYSTEM CHART................................................. 8-19

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
