FRONT BRAKE HOSE ROUTING
Brake hose union
Stopper
Throttle cable
Tighten the brake hose union bolt to the
specified torque, after touching the brake
hose union to the stopper.
Pass the brake hose under the
throttle cables.
Brake hose guide
Bolt
Brake hose
Brake hose
Throttle cable guide
Brake hose clamp
Fix the brake hose to
the clamp firmly.
Fix the brake hose to
the clamp firmly.
Pass through the brake
hose into the it guide.
Brake hose guide
Brake hose guide
14˚
14˚
Tighten the brake hose union bolt to the
specified torque, after touching the brake
hose union to the stopper.
15- 18 VZR1800N ('08-MODEL)

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
