5-18 FI SYSTEM DIAGNOSIS
DEALER MODE
The defective function is memorized in the computer. Use the special tool’s coupler to connect to the dealer
mode coupler. The memorized malfunction code is displayed on LCD (DISPLAY) panel. Malfunction means
that the ECM does not receive signal from the devices. These affected devices are indicated in the code
form.
! 09930-82720: Mode select switch
"
Before checking the malfunction code, do not disconnect the ECM lead wire couplers.
If the couplers from the ECM are disconnected, the malfunction code memory is erased and the
malfunction code can not be checked.
MALFUNCTION
LCD (DISPLAY)
INDICATION
FI INDICATOR LIGHT
INDICATION
INDICATION MODE
“NO” C00
FI indicator light turns OFF.
----
“YES”
C**code is indicated from
small numeral to large
one.
For each 2 sec., code is
indicated.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
