Suzuki VZR1800 2008 User Manual

5-28 FI SYSTEM DIAGNOSIS
MALFUNCTION CODE AND DEFECTIVE CONDITION
DTC No.
DETECTED
ITEM
DETECTED FAILURE CONDITION CHECK FOR
C00 NO FAULT
––––––––––– –––––––––––
C12
CKP sensor The signal does not reach ECM for 3
sec. or more, after receiving the starter
signal.
CKP sensor wiring and mechan-
ical parts
CKP sensor, lead wire/coupler
connection
P0335
C13/C17
IAP sensor The sensor should produce following
voltage.
0.5 V sensor voltage < 4.85 V
In other than the above range, C13
(P1750) or C17 (P0105) is indicated.
IAP sensor, lead wire/coupler
connection
P1750/P0105
P1750/
P0105
H
Sensor voltage is higher than specified
value.
IAP sensor circuit shorted to
VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
IAP sensor circuit open or
shorted to ground or VCC circuit
open
C14
TP sensor The sensor should produce following
voltage.
0.2 V sensor voltage < 4.80 V
In other than the above range, C14
(P0120) is indicated.
TP sensor, lead wire/coupler
connection
P0120
P0120
H
Sensor voltage is higher than specified
value.
TP sensor circuit shorted to
VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
TP sensor circuit open or
shorted to ground or VCC circuit
open
C15
ECT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C15
(P0115) is indicated.
ECT sensor, lead wire/coupler
connection
P0115
P0115
H
Sensor voltage is higher than specified
value.
ECT sensor circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
ECT sensor circuit shorted to
ground
C21
IAT sensor The sensor voltage should be the fol-
lowing.
0.15 V sensor voltage < 4.85 V
In other than the above range, C21
(P0110) is indicated.
IAT sensor, lead wire/coupler
connection
P0110
P0110
H
Sensor voltage is higher than specified
value.
IAT sensor circuit open or
ground circuit open
L
Sensor voltage is lower than specified
value.
IAT sensor circuit shorted to
ground

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
