FI SYSTEM DIAGNOSIS 5-11
COMPENSATION OF INJECTION TIME (VOLUME)
The following different signals are output from the respective sensors for compensation of the fuel injection
time (volume).
INJECTION STOP CONTROL
SIGNAL DESCRIPTION
ENGINE COOLANT TEMPERATURE SEN-
SOR SIGNAL
When engine coolant temperature is low, injection time (vol-
ume) is increased.
INTAKE AIR TEMPERATURE SENSOR
SIGNAL
When intake air temperature is low, injection time (volume)
is increased.
HEATED OXYGEN SENSOR SIGNAL
(FOR E-02, 19, 24)
Air/fuel ratio is compensated to the theoretical ratio from
density of oxygen in exhaust gasses. The compensation
occurs in such a way that more fuel is supplied if detected
air/fuel ratio is lean and less fuel is supplied if it is rich.
BATTERY VOLTAGE SIGNAL ECM operates on the battery voltage and at the same time,
it monitors the voltage signal for compensation of the fuel
injection time (volume). A longer injection time is needed to
adjust injection volume in the case of low voltage.
ENGINE RPM SIGNAL At high speed, the injection time (volume) is increased.
STARTING SIGNAL When starting engine, additional fuel is injected during
cranking engine.
ACCELERATION SIGNAL/
DECELERATION SIGNAL
During acceleration, the fuel injection time (volume) is
increased, in accordance with the throttle opening speed
and engine rpm. During deceleration, the fuel injection time
(volume) is decreased.
SIGNAL DESCRIPTION
TIP-OVER SENSOR SIGNAL
(FUEL SHUT-OFF)
When the motorcycle tips over, the tip-over sensor sends a
signal to the ECM. Then, this signal cuts OFF current sup-
plied to the fuel pump, fuel injectors and ignition coils.
OVER-REV. LIMITER SIGNAL The fuel injectors stop operation when engine rpm reaches
rev. limit rpm.
To Next Page
