5-100 FI SYSTEM DIAGNOSIS
HO2 SENSOR INSPECTION
(FOR E-02, 19, 24)
The heated oxygen sensor is installed on the pre-muffler.
(#5-79)
HO2 SENSOR REMOVAL AND
INSTALLATION (FOR E-02, 19, 24)
• Remove the HO2 sensor unit.
+
"
• Install the HO2 sensor in the reverse order of removal.
"
• Tighten the sensor unit to the specified torque.
* HO2 SENSOR: 48 N·m (4.8 kgf-m, 34.5 lb-ft)
Do not remove the HO2 sensor while it is hot.
* Be careful not to expose it to excessive shock.
* Do not use an impact wrench while removing or
installing the HO2 sensor unit.
* Be careful not to twist or damage the sensor lead
wire.
Do not apply oil or other materials to the sensor air
hole.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
