ENGINE 3-51
CLUTCH RELEASE CAMSHAFT
DISASSEMBLY
• Remove the clutch release arm 1, return spring 2 and
washer 3.
• Pull out the oil seal 4, bearing 5 with the clutch release cam-
shaft 6.
"
• Remove the clutch push rod cap 7 and oil seal 8.
"
REASSEMBLY
• Apply SUZUKI SUPER GREASE “A” the release camshaft 1,
new bearing 2 and oil seal 3 before installing.
) 99000-25010: SUZUKI SUPER GREASE “A”
or equivalent
• Install the clutch release arm and tighten the bolt 1.
NOTE:
Align the release arm punch mark A with the notch mark B on
the release camshaft.
The removed oil seal and bearing must be replaced
with new one.
The removed oil seal must be replaced with new one.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
