Suzuki VZR1800 2008 User Manual

CHASSIS 9-11
REASSEMBLY AND INSTALLATION
Reassemble and install the front wheel in the reverse order of
removal and disassembly. Pay attention to the following points:
WHEEL BEARING
• Apply SUZUKI SUPER GREASE “A” to the wheel bearings.
' 99000-25010: SUZUKI SUPER GREASE “A”
or equivalent
23 N·m
(2.3 kgf-m, 16.5 lb-ft)
23 N·m
(2.3 kgf-m, 16.5 lb-ft)
100 N·m
(10.0 kgf-m, 72.5 lb-ft)
Left Right

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
