7-2 EXHAUST SYSTEM
EXCVA (EXHAUST CONTROL VALVE ACTUATOR) AND EXCV
(EXHAUST CONTROL VALVE)
EXCVA AND EXCV REMOVAL
• Turn the ignition switch OFF.
• Remove the left frame side cover. (!9-5)
• Connect the special tool (Mode select switch) to the dealer
mode coupler. (!5-18)
• After turning the special tool’s switch ON, turn the ignition
switch ON.
" 09930-82720: Mode select switch
• Remove the rubber cover 1.
• Check the cable slots A of the EXCVA pulley face backward
(adjustment position) as shown.
• Turn the ignition switch OFF.
#
• Remove the exhaust pipe and muffler. (!7-8)
• Remove the EXCVA cover 2.
• Hold the EXCVA pulley with an adjustable wrench, and
loosen the pulley mounting bolt.
#
Before removing the EXCVA, be sure to set the EXCVA
pulley to the adjustment position.
* When loosening or tightening the pulley bolt, be sure
to fix the pulley with an adjustable wrench, or EXCVA
may get damaged.
* Do not use the adjustable wrench to turn EXCVA pul-
ley so as not to cause damage to the internal gear of
EXCVA.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
