Suzuki VZR1800 2008 User Manual

11-22 SERVICING INFORMATION
TIGHTENING TORQUE
ENGINE
ITEM N·m kgf-m lb-ft
Cylinder head cover bolt 11 1.1 8.0
Cylinder head cover cap bracket bolt 11 1.1 8.0
Cylinder head bolt M: 6 11 1.1 8.0
M: 8 26 2.6 19.0
M: 10
Initial 25 2.5 18.0
Final 42 4.2 30.5
Cylinder nut 13 1.3 9.5
Cylinder head plug (Water jacket plug) 26 2.6 19.0
Camshaft housing bolt 11 1.1 8.0
Sprocket cam chain drive bolt 85 8.5 61.5
Cam chain tension No.1 adjuster bolt 10 1.0 7.0
Cam chain tension No.2 adjuster bolt 10 1.0 7.0
Cam chain tension adjuster cap bolt 23 2.3 16.5
Cam chain tensioner bolt (No.1 & No.2) 18 1.8 13.0
Cam chain tensioner No.2 nut 10 1.0 7.0
Cam chain guide No.1 bolt 18 1.8 13.0
Exhaust pipe bolt 23 2.3 16.5
Muffler mounting bolt and nut 23 2.3 16.5
Oxygen sensor (For E-02, 19, 24) #1 & #2 48 4.8 34.5
Spark plug 11 1.1 8.0
Primary driven gear bolt 95 9.5 68.5
Starter clutch bolt 25 2.5 18.0
Crank balancer drive gear bolt 24 2.4 17.5
Crank balancer driven gear bolt M: 6 10 1.0 7.0
M: 8 25 2.5 18.0
Conrod bearing cap bolt Initial 35 3.5 25.5
Final
After tightening to the above torque,
tighten 1/4 of a turn (90°)
Oil drain plug 23 2.3 16.5
Crankcase bolt M: 6 11 1.1 8.0
M: 8 26 2.6 19.0
M: 10
Initial 30 3.0 21.5
Final 50 5.0 36.0
Oil gallery plug M: 6 10 1.0 7.0
M: 10 16 1.6 11.5
M: 12 21 2.1 15.0
M: 14 25 2.5 18.0
M: 16 35 3.5 25.5
Oil cooler union bolt 70 7.0 50.5
Oil pressure switch 14 1.4 10.0
Oil pressure switch lead wire screw 1.5 0.15 1.0
Clutch sleeve hub nut 95 9.5 68.5

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
