Suzuki VZR1800 2008 User Manual

COOLING AND LUBRICATION SYSTEM 8-13
WATER PUMP
REMOVAL AND DISASSEMBLY
NOTE:
Before draining engine oil and engine coolant, inspect engine oil
and coolant leakage between the water pump and crankcase. If
engine oil is leaking, visually inspect the oil seal and O-ring. If
engine coolant is leaking, visually inspect the mechanical seal
and seal washer. (#8-15)
• Remove the secondary gear case cover. (#3-6)
• Drain the engine coolant. (#2-20)
• Drain the engine oil. (#2-17)
• Remove the water outlet pipe mounting bolts.
• Disconnect the water hoses.
• Remove the water pump 1 and disconnect the water hose
2.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
