EMISSION CONTROL INFORMATION 12-3
CRANKCASE EMISSION CONTROL SYSTEM
The engine is equipped with a PCV system to prevent discharging crankcase emissions into the atomo-
sphere. Blow-by gas in the engine is constantly drawn into the crankcase, which is returned to the combus-
tion chamber through the PCV (breather) hose, air cleaner and throttle body.
1 PAIR control solenoid valve C EXHAUST GAS
2 PCV hose D BLOW-BY GAS
A FRESH AIR E RETURN OIL
B FUEL/AIR MIXTURE

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
