6-10 FUEL SYSTEM AND THROTTLE BODY
FUEL MESH FILTER INSPECTION
• Disconnect the clamp 1 and rubber boot 2.
If the fuel mesh filter is clogged with sediment or rust, replace
the fuel filter with a new one.
FUEL PUMP AND FUEL LEVEL GAUGE
REASSEMBLY AND INSTALLATION
Install the fuel pump and fuel level gauge in the reverse order of
removal and disassembly. Pay attention to the following points:
• Apply thin coat of engine oil to the new bushing and install if to
the fuel joint pipe.
"
• Install the new O-ring to the pressure regulator.
• Apply thin coat of the engine oil to the new O-ring.
"
• Install the new O-ring to the fuel pipe.
• Apply thin coat of the engine oil to the new O-ring.
"
Use the new bushing to prevent fuel leakage.
Use the new O-ring to prevent fuel leakage.
Use the new O-ring to prevent fuel leakage.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
