Suzuki VZR1800 2008 User Manual

7-6 EXHAUST SYSTEM
EXCVA ADJUSTMENT
1st step:
• Set the EXCVA to adjustment position. (!7-2)
• Make sure that the No. 2 cable and No. 1 cable are fixed into
the clamp.
2nd step:
• Turn the mode select switch OFF.
• Turn the ignition switch ON to check the EXCVA operation.
• Turn the mode select switch ON.
• If C46 is not indicated on the LCD (DISPLAY), the adjustment
is correctly completed. In this case, it is unnecessary to pro-
ceed to 3rd step.
• If C46 is indicated, repeat the adjustment procedure from 3rd
and 4th step.
3rd step:
• This procedure is only required when C46 is indicated.
• Turn the ignition switch OFF.
• Remove the lower frame cover. (!7-8)
• Insert the two copper wires into the back side of the position
sensor lead wire coupler 1.
• Disconnect the EXCVA motor lead wire coupler 2.
ON OFF

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
