Suzuki VZR1800 2008 User Manual

ENGINE 3-9
ENGINE INSTALLATION
Install the engine in the reverse order of engine removal.
Pay attention to the following points:
• Install the boot and universal joint.
NOTE:
Make sure that the “UP” mark A faces up.
• Gradually raise the engine, and then engage the secondary
driven gear shaft to the universal joint.
• Properly fit the boot onto the engine and the swingarm.
"
• Install the engine mounting bracket 1 and tighten it bolts to
the specified torque.
# Engine mounting bracket bolt (rear):
23 N·m (2.3 kgf-m, 16.5 lb-ft)
• Install the engine mounting bolts and nuts and tighten to the
specified torque. (!3-11)
Be careful not to catch the wiring harness between the
frame and the engine.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
