PERIODIC MAINTENANCE 2-33
SDS CHECK
Using SDS, take the sample of data from the new motorcycle and at the time of periodic maintenance at
your dealership.
Save the data in the computer or by printing and filing the hard copies. The saved or filed data are useful for
troubleshooting as they can be compared periodically with changes over time or failure conditions of the
motorcycle.
For example, when a motorcycle is brought in for service but the troubleshooting is difficult, comparison with
the normal data that have been saved or filed can allow the specific engine failure to be determined.
• Remove the left frame side cover. (!9-5)
• Set up the SDS tool. (!5-25)
" 09904-41010: SDS set tool
99565-01010-007: CD-ROM Ver. 7
NOTE:
* Before taking the sample of data, check and clear the Past DTC. (!5-26)
* A number of different data under a fixed condition as shown below should be saved or filed as sample.
SAMPLE:
Data sampled from cold starting through warm-up
Check the engine r/min.
XXXX r/min
Check the water temperature.
XX ˚C
Check the manifold absolute pressure #1.
XX mmHg
Check the manifold absolute pressure #2.
XX mmHg
˚

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
