9-64 CHASSIS
• Inspect the pad mounting pin for bent or damage. If any
defects are found, replace the pad mounting pins with the new
ones.
• Install the new brake pads.
• Install the brake caliper.
• Tighten the rear brake caliper mounting bolt to the specified
torque.
# Rear brake caliper mounting bolt:
39 N·m (3.9 kgf-m, 28.0 lb-ft)
NOTE:
After replacing the brake pads, pump the brake pedal a few
times to check for proper brake operation and then check the
brake fluid level.
BRAKE FLUID REPLACEMENT
• Remove the right frame head cover and right radiator cover.
(!9-6)
• Place the motorcycle on a level surface.
• Remove the brake fluid reservoir cap 1 and diaphragm.
• Drain the old brake fluid as much as possible.
• Fill the reservoir with new brake fluid.

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
