12-6 EMISSION CONTROL INFORMATION
PAIR (AIR SUPPLY) SYSTEM AND EMISSION CONTROL SYSTEM
INSPECTION
PAIR HOSES
• Remove the frame head covers. (!9-6)
• Inspect the PAIR hoses for wear or damage.
• Inspect the PAIR hoses for secure connection.
PAIR REED VALVE
• Remove the fuel tank. (!6-3)
• Remove the PAIR reed valve cover. (!3-29)
• Inspect the reed valve for the carbon deposit.
• If the carbon deposit is found in the reed valve, replace the
PAIR reed valve with a new one.
PAIR CONTROL SOLENOID VALVE
REMOVAL
• Remove the air cleaner chamber. (!6-13)
• Remove the PAIR control solenoid valve 1.
INSPECTION
• Check that air flows through the air inlet port to the air outlet
port.
• If air does not flow out, replace the PAIR control solenoid
valve with a new one.
A Air flow
• Connect the 12 V battery to the PAIR control solenoid valve
terminals and check the air flow.
• If air does not flow out, the solenoid valve is in normal condi-
tion.
12V

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
