2-16 PERIODIC MAINTENANCE
SPARK PLUG INSTALLATION
• Screw the spark plugs into the cylinder head with fingers, and
then tighten them to the specified torque.
# Spark plug: 11 N·m (1.1 kgf-m, 8.0 Ib-ft)
"
IGNITION COIL/PLUG CAP INSTALLATION
• Install the ignition coils/plug caps and connect their lead wire
couplers.
"
FUEL LINE
• Inspect the fuel feed hose 1 for damage and fuel leakage. If
any defects are found, the fuel feed hose must be replaced.
EVAPORATIVE EMISSION CONTROL
SYSTEM (E-33 ONLY)
Inspect the evaporative emission control system periodically.
Do not cross thread or over tighten the spark plug, or
such an operation will damage the aluminum threads
of the cylinder head.
* Do not hit the ignition coil/plug cap with a plastic
hammer when installing it.
* Place the ignition coil/spark plug cap so that the cou-
pler does not touch the cylinder head cover.
CONTACT
INCORRECT
INCORRECT
Inspect every 6 000 km (4 000 miles, 12 months).
Inspect every 12 000 km (7 500 miles, 24 months).

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
