CHASSIS 9-69
RUBBER BOOT
• Set the rubber boot onto the brake caliper.
CALIPER INSTALLATION
Install the caliper in the reverse order of removal. Pay attention
to the following points:
• Install the brake pads and brake caliper. (!9-64)
• Tighten brake hose union bolt to the specified torque.
(Rear brake hose routing:!11-40)
# Brake hose union bolt: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
$
BRAKE DISK INSPECTION (!9-58)
& Rear disc thickness: Service Limit: 6.3 mm (0.25 in)
MASTER CYLINDER REMOVAL
• Remove the right frame head cover and right radiator cover.
(!9-6)
• Remove the exhaust pipe and muffler. (!7-8)
• Drain the brake fluid. (!9-64)
NOTE:
Temporarily tighten the reservoir cap.
• Remove the brake fluid reservoir mounting bolt.
• Remove the master cylinder cover 1.
* The seal washers should be replaced with the new
ones to prevent brake fluid leakage.
* Bleed air from the system after reassembling the cal-
iper. (!2-26)

Suzuki VZR1800 2008 Specifications

General

Displacement	1783 cc
Bore x Stroke	112.0 mm x 90.5 mm
Compression Ratio	10.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Engine Type	4-stroke, liquid-cooled, DOHC, V-twin
Front Tire	130/70R18M/C 63H
Overall Length	2485mm (97.8 inches)
Overall Height	1185 mm
Ground Clearance	140 mm (5.5 in)
Seat Height	705 mm
Curb Weight	347 kg
