SERVICING INFORMATION 11-53
LICENSE LIGHT AND LICENSE PLATE INSTALLATION
BRAKE LIGHT/TAILLIGHT INSTALLATION
1 License light 4 Washer "
2 License plate 5 Spacer ITEM N·m
kgf-m
lb-ft
3 Nut A License light nut A 50.53.5
1 Rear frame cover 2 Brake light/Taillight

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki VZR1800 2008 and is the answer not in the manual?

Suzuki VZR1800 2008 Specifications

General IconGeneral
Displacement1783 cc
Bore x Stroke112.0 mm x 90.5 mm
Compression Ratio10.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission5-speed constant mesh
Final DriveShaft drive
Front SuspensionInverted telescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front BrakesDual hydraulic disc
Rear BrakesSingle hydraulic disc
Engine Type4-stroke, liquid-cooled, DOHC, V-twin
Front Tire130/70R18M/C 63H
Overall Length2485mm (97.8 inches)
Overall Height1185 mm
Ground Clearance140 mm (5.5 in)
Seat Height705 mm
Curb Weight347 kg
