Xerox WorkCentre 4150 Service Manual

January 2016
viii
WorkCentre WorkCentre 4150/4250/42604150/4250/4260WorkCentre 4150/
Change History, Warnings, Cautions and Notes
Introduction
• ADJ 14.4 Scan Geometry Adjustment (4265)
• dC104 Usage Counters (4265)
• dC108 Software Version (4265)
• dC120 Fault Counters (4265)
• dC122 Fault History (4265)
• dC135 High Frequency Service Items (4265)
• dC612 Print Test Pattern (4265)
• PWB Connectors: DADF CCD PWB (4265)
• PWB Connectors: Power Supply Unit 2 (4265)
• PWB Connectors: Switched Mode Power Supply (4265)
• PWB Connectors: User Interface PWB (4265)
• PWB Connectors: DADF PWB (4265)
• PWB Connectors: OPE Sub PWB (4265)
• PWB Connectors: OPE Key PWB
• PWB Connectors: Scanner PWB (4265)
• PWB Connectors: Scanner CCD PWB (4265)
• PWB Connectors: HVPS (4265)
• PWB Connectors: Main PWB (4265)
• Wiring Diagram 33 (4265)
• Wiring Diagram 34 (4265)
• Wiring Diagram 35 (4265)
• Wiring Diagram 36 (4265)
• Wiring Diagram 37 (4265)
• Wiring Diagram 38 (4265)
• Wiring Diagram 39 (4265)
• Wiring Diagram 40 (4265)
• Wiring Diagram 41 (4265)
• Wiring Diagram 42 (4265)
• Wiring Diagram 43 (4265)
• Wiring Diagram 44 (4265)
• Wiring Diagram 45 (4265)
Warnings, Cautions and Notes
A translated version of all warnings is in Translation of Warnings.
WARNING
A warning is used whenever an operating or maintenance procedure, practice, condi-
tion or statement, if not strictly observed, could result in personal injury.
CAUTION
A caution is used whenever an operation or maintenance procedure, practice, condition or
statement, if not strictly observed, could result in damage to the equipment.
NOTE: A note is used where it is essential to highlight a procedure, practice, condition or state-
ment.
The following are examples of the symbols that are used in this manual for an electrostatic
damage caution and laser radiation warning.
ESD caution symbol
CAUTION
Certain components in this product are susceptible to damage from electrostatic discharge.
Observe all ESD procedures to avoid component damage.
Laser radiation warning symbol.
WARNING
Follow the service procedure exactly as written. Use of controls or adjustments other
than those specified in this manual, may result in an exposure to invisible laser radia-
tion. During servicing, the invisible laser radiation can cause eye damage if looked at
directly.
