Xerox WorkCentre 4150 Service Manual

January 2016
6-8
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/
GP 2
General Procedures and Information
GP 2 Fault Codes and History Files
Purpose
To explain the chain code structure and describe fault history contents.
Description
• To access some history files from the UI, refer to GP 3 machine Status.
• To view all the machine fault history, clear the last 40 faults, or reset each of the fault
counters, refer to Diagnostics Fault History.
• For information on fault codes, refer to Function and Fault Codes.
Procedure
1. Enter diagnostics, GP 1.
2. Select Service Information tab.
3. Select dC 120 Fault Counters or dC122 Fault History as appropriate and follow the on
screen instructions.
Function and Fault Codes
Refer to Table 1 Function and fault code prefixes. Also known as the chain code.
NOTE: Where possible, the component related fault codes are the same as the component
control codes.
Machine Status Button Fault History
The most recent fault and status codes can be displayed on the UI. Press the Machine Status
button, refer to GP 3. Touch the ‘Error Messages’ tab on the UI, then select, as appropriate:
•All Faults.
• Active Messages - status codes and a status message.
• Event Log.
Diagnostics Fault History
Description
The diagnostics Fault History window contains two options:
1. Fault Log - Displays the faults in time or code order. Displays a selected fault in detail.
Permits deletion of the entire history file.
2. Fault Counters - Displays the title buttons for the faults separated into chains. Selection of
a chain will display the fault detail.
NOTE: . Categories that do not exist on the machine will not be displayed.
Diagnostics Fault History (4265)
Description
To access dC120 Fault Counters or dC122 Fault History, enter Diagnostics and select Ser-
vice Information.
• dC120 Fault Counters - Displays the Fault Code, Component Name, and Occurrence.
• dC122 Fault History - Displays Fault Code, Component Name, Date and Time.
Table 1 Function and fault code prefixes
Chain Code Function
01 Electrical
02 User Interface
03 Run control
04 Drives and fans
05 DADF
06 LSU (ROS)
07 Paper tray
08 Paper feed
09 Xerography
10 Fusing
12 Finisher
15 Scan to Email
16 Network Controller
17 Network
20 Fax
