Xerox WorkCentre 4150 Service Manual

January 2016
6-72
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
dC330, dC606
General Procedures and Information
dC606 Internal Print Test Patterns
Purpose
To print internal test patterns for image quality analysis.
NOTE: To print out test patterns on the 4265 machine, go to dC612
Procedure
1. Enter diagnostics, GP 1.
2. Enter Diagnostics Routines.
3. Enter Other Routines.
4. Enter dC606 Print Test Patterns.
5. Select the relevant test pattern.
NOTE: Refer to IQ1 Image Quality Entry RAP for information on the test patterns.
6. Select the Features, 1 or 2 sided and the paper tray.
7. Touch the Start Test.
8. Press Exit to return to the main diagnostic menu; select another feature or exit diagnos-
tics.
20-028 DTMF 6 Line1 Emits DTMF 6 on line 1. On/Off.
20-029 DTMF 7 Line1 Emits DTMF 7 on line 1. On/Off.
20-030 DTMF 8 Line1 Emits DTMF 8 on line 1. On/Off.
20-031 DTMF 9 Line1 Emits DTMF 9 on line 1. On/Off.
20-040 V.21 300 bps Line1 Emits V.21 300 bps on line 1. On/Off.
20-041 V.27ter 2400 bps Line1 Emits V27ter 2400 bps on line 1. On/Off.
20-042 V.27ter 4800 bps Line1 Emits V27ter 4800 bps on line 1. On/Off.
20-043 V.29 7200 bps Line1 Emits V.29 7200 bps on line 1. On/Off.
20-044 V.29 9600 bps Line1 Emits V.29 9600 bps on line 1. On/Off.
20-045 V.17 7200 bps Line1 Emits V.17 7200 bps on line 1. On/Off.
20-046 V.17 9600 bps Line1 Emits V.17 9600 bps on line 1. On/Off.
20-047 V.17 12000 bps Line1 Emits V.17 12000 bps on line 1. On/Off.
20-048 V.17 14400 bps Line1 Emits V.17 14400 bps on line 1. On/Off.
20-049 V.34 2400 bps Line1 Emits V.34 2400 bps on line 1. On/Off.
20-050 V.34 4800 bps Line1 Emits V.34 4800 bps on line 1. On/Off.
20-051 V.34 7200 bps Line1 Emits V.34 7200 bps on line 1. On/Off.
20-052 V.34 9600 bps Line1 Emits V.34 9600 bps on line 1. On/Off.
20-053 V.34 12000 bps Line1 Emits V.34 12000 bps on line 1. On/Off.
20-054 V.34 14400 bps Line1 Emits V.34 14400 bps on line 1. On/Off.
20-055 V.34 16800 bps Line1 Emits V.34 16800 bps on line 1. On/Off.
20-056 V.34 19200 bps Line1 Emits V.34 19200 bps on line 1. On/Off.
20-057 V.34 21600 bps Line1 Emits V.34 21600 bps on line 1. On/Off.
20-058 V.34 24000 bps Line1 Emits V.34 24000 bps on line 1. On/Off.
20-059 V.34 26400 bps Line1 Emits V.34 26400 bps on line 1. On/Off.
20-060 V.34 28800 bps Line1 Emits V.34 28800 bps on line 1. On/Off.
20-061 V.34 31200 bps Line1 Emits V.34 31200 bps on line 1. On/Off.
20-062 V.34 33600 bps Line1 Emits V.34 33600 bps on line 1. On/Off.
20-063
(4265)
On Line Quiet State Initiates the On Line Quiet State On/Off
Table 20 Output codes 20
Code Displayed Name Description General
