Xerox WorkCentre 4150 Service Manual

January 2016
1-6
WorkCentre WorkCentre 4150/4250/4260WorkCentre 4150/4250/42604150/
SCP 5
Service Call Procedures
SCP 5 Subsystem Maintenance
Subsystem Maintenance contains information regarding the component life of the machine.
Procedure
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer
supply while performing tasks that do not need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
Go to the relevant procedure:
• Component Life
• HFSI
Component Life
The design life of the major components are shown in Table 1, Table 2, and Table 3. Environ-
mental conditions and actual use will vary these factors. The component life shown is for refer-
ence only. Refer to the relevant table:
• Table 1 WorkCentre 4150
• Table 2 WorkCentre 4250/4260
• Table 3 WorkCentre 4265
Table 1 WorkCentre 4150
Part Component life Parts list reference
DADF retard pad 50k feeds PL 5.20 Item 12
DADF feed roll assembly 200k feeds PL 5.15 Item 5
Tray 1 feed roll 200k feeds PL 8.10 Item 12
Tray 2, 3 and 4 feed roll 200k feeds PL 8.10 Item 12
Transfer roll 100k prints PL 7.35 Item 19
Fuser assembly 200k prints PL 10.25 Item 1
Starter toner cartridge
Toner cartridge
10K prints
20K prints
PL 9.10 Item 2
Xerographic module 55K prints PL 9.10 Item 1
Table 2 WorkCentre 4250/4260
Part Component life Parts list reference
DADF retard pad 125k feeds PL 5.45 Item 4
DADF feed roll assembly 250k feeds PL 5.40 Item 7
Tray 1 feed roll 250k feeds PL 8.10 Item 12
Tray 2, 3 and 4 feed roll 250k feeds PL 8.10 Item 12
HCF feed roll 250k feeds PL 8.10 Item 12
Transfer roll 125k prints PL 7.35 Item 19
Fuser assembly 250k prints PL 10.28 Item 1
Starter toner cartridge
Toner cartridge
12k prints
23k prints
PL 9.10 Item 2
Xerographic module 80k prints PL 9.10 Item 1
Table 3 WorkCentre 4265
Part Component life Parts list reference
DADF retard pad 125k feeds PL 5.70
DADF Pickup Roll assembly 250k feeds PL 5.70
Tray 1 feed roll 250k feeds PL 8.10 Item 12
Tray 2, 3 and 4 feed roll 250k feeds PL 8.10 Item 12
HCF feed roll 250k feeds PL 8.10 Item 12
Transfer roll 125k prints PL 7.35 Item 19
Fuser assembly 250k prints PL 10.28 Item 1
Starter toner cartridge
Toner cartridge
10k prints
25k prints
PL 9.10 Item 2
Xerographic module 100k prints PL 9.10 Item 1
