Yamaha ttr230 User Manual

SPEC
CONTENTS
GENERAL SPECIFICATIONS ......................................................................... 2-1
MAINTENANCE SPECIFICATIONS . .............................................................. 2-4
ENGINE ............................................................................................ 2-4
FRAME ........................................................................................... 2-11
ELECTRIC SYSTEM ....................................................................... 2-15
GENERAL TORQUE SPECIFICATIONS ....................................................... 2-17
UNIT DEFINITION ......................................................................................... 2-17
LUBRICATION POINTS AND LUBRICANT TYPES ..................................... 2-18
ENGINE .......................................................................................... 2-18
FRAME ........................................................................................... 2-19
LUBRICATION DIAGRAM ............................................................................ 2-20
CABLE ROUTING ......................................................................................... 2-22
HANDLE BAR ................................................................................ 2-22
FRONT ............................................................................................ 2-23
MOTORCYCLE – RIGHT SIDE ....................................................... 2-24
MOTORCYCLE – LEFT SIDE ......................................................... 2-25
INTERNAL OPENING ..................................................................... 2-26
BATTERY AND COMPONENTS .................................................... 2-27
CHAPTER 2.
SPECIFICATIONS

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
