SPEC
2-18
Symbol Lubrication points
ENGINE
LUBRICATION POINTS AND LUBRICANT TYPES
LUBRICATION POINTS AND LUBRICANT TYPES
Retainer lips (all)
Roller bearings (all)
Bolts (head)
Crankshaft pin
Connecting rod (lower portion)
Piston and piston rings
Piston pin
Valve stem and guides
Retainer (valve stem)
Rocker shaft and rocker
Cams and roller bearing (Camshaft)
O-ring (Drain plug)
Clutch bar
Primary gear and main shaft
Gearbox
Shift lever
Crankcase surfaces Yamaha Bond nº1215 Glue

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
