Yamaha ttr230 User Manual

INFO
GEN
MOTORCYCLE IDENTIFICATION .................................................................. 1-1
FRAME NUMBER ............................................................................ 1-1
MODEL IDENTIFICATION ................................................................ 1-1
IMPORTANT INFORMATION ......................................................................... 1-2
PREPARING FOR REMOVING AND DISMOUNTING ..................... 1-2
REPLACEMENT PARTS .................................................................. 1-3
GASKETS, RETAINERS AND O-RINGS .......................................... 1-3
LOCK WASHERS/SPACERS AND COTTER PINS .......................... 1-3
ROLLER BEARINGS AND RETAINERS .......................................... 1-3
LOCK RINGS .................................................................................... 1-4
SPECIAL TOOLS ............................................................................................ 1-4
FOR ADJUSTING ............................................................................. 1-4
FOR ENGINE SERVICES .................................................................. 1-5
FOR FRAME SERVICES .................................................................. 1-8
FOR ELECTRIC COMPONENTS ...................................................... 1-9
CONTENTS
CHAPTER 1.
GENERAL INFORMATION

Yamaha ttr230 Specifications

General

Engine Type	223cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke	70.0mm x 58.0mm
Compression Ratio	9.5:1
Ignition	CDI
Transmission	Constant-mesh 6-speed; multiplate wet clutch
Final Drive	Chain
Rear Suspension	Single shock; 8.7-in travel
Front Tire	80/100-21
Rear Tire	100/100-18
Length	81.3 in
Width	31.5 in
Seat Height	34.3 in
Wheelbase	54.5 in
Ground Clearance	11.6 in
Front Suspension	Telescopic fork
Rear Brake	Drum
